Описание

Applicable to 24V/36V/48V/60V/72V battery pack system, user can set the output voltage and current according to actual need.
Innovative MPPT technology, high tracking efficiency, which can improve the generated energy.
High-speed and high-performance design, great for solar charging use.
Excellent heat dissipation capability: adopts advanced fan temperature control technology for quick control the heat.
Aluminum alloy casing and portable size, durable for use.
Simple operation interface: clear LCD color display the current, current, power, charging time, etc.
Working modes: MPPT and DC-DC selectable, MPPT for photovoltaic panels application and DC-DC for boost power supply.
Charging selection: applicable to lithium battery and accumulator cell.
Built-in 20 groups of data for user to set and store, support for multi-purpose.
Max. output power is 600W, best suitable for 100W-600W solar panel; the greater the power, the MPPT effect is more obvious.
With reverse charging protection: avoid the accumulator cell reversely charge the solar battery.
Reverse connecting protection: MOS reverse protection circuit for input and output end to effectively protect the controller and battery .
Overload protection: the controller will automatically cut off circuit if overload.
Wide application range: storage battery pack and lithium battery pack charging, home PV power system, solar streetlight, etc.
Specifications:
Color: Green
Material: Aluminum Alloy
Display: 160x128 TFT Color LCD Display
Input Voltage: DC 12-60V
Output Voltage: DC 15-90V, Adjustable to accommodate 24V/36V/48V/60V/72V Battery
Output Current: 0-10A Adjustable
Output Power: 20-600W
Working Modes: MPPT and DC-DC
Item Size: 131 x 96 x 54mm / 5.2 x 3.8 x 2.2in
Package Includes:1 x MPPT Solar Charge Controller
1 x User Manual (English)
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.

|

ВсеТовар мы можем отгрузить в течение 5-8 рабочих дней, обычно мыВ зависимости от времени заказа клиента для упаковки и отгрузки, мы должныВнимательно проверьте качество товара перед отправкой, поэтому ВозьмитеВремени, чтобы справиться с этим. Время доставки: Из-заК факторам форс-мажорных обстоятельств: ураганы, дождевые штормы влияют на полеты. ВедущийДля того чтобы логистика задержки. Мы честные продавцы, не дадим вам страдатьПотери. Пожалуйста, дайте логистической компании немного времени на обработку, мыПодождите, пока посылка дойдет до вашей стороны. Если ваша информация о логистике поступает в местное почтовое отделение: В том случае, еслиМестное почтовое отделение не свяжется с вами, пожалуйста, свяжитесь с вашимМестное почтовое отделение как можно скорее, чтобы получить посылка. В противном случаеСверхурочное получение посылок, местное почтовое отделение вернет вамПосылка, ответственность за себя. Время защиты заканчивается: В тех случаях, когдаМы закончили время отгрузки, если срок защиты продуктаНа исходе, пожалуйста, увеличьте срок защиты продукта самостоятельно илиСвяжитесь с нами, пожалуйста, не открывайте спор напрямую. Ввозные таможенные пошлины: НалогиИ сборы не включены в стоимость товара или стоимость доставки.Ответственность за эти расходы несет покупатель. Ввозные пошлины, налоги иРасходы не включены в стоимость товара или стоимость доставки. ЭтиРасходы оплачиваются покупателем




Характеристики
- Применение
- Контроллер зарядного устройства
- Номер модели
- Solar Charge Controller
- Максимальный Ток
- 0-10A Adjustable
- Output Power
- 20-600W
