90-120PSI 4 Порты и разъёмы воздушный компрессор с приводом от двигателя откачивающий насос Давление Управление коммутационная арматура с датчиками практичный

Features:
This switch is used to control the pressure in the motor-driven air compressor cylinder to operate between two preset pressure values.
The working pressure of the safety relief is 120PSI. If you adjust the pressure switch over 120PSI, you need replace it with new one.
The pressure switch has an overflow that allows the air compressor to avoid overload starting.
The four-way base interface makes it easier to install the exhaust and pressure gauge.
Specifications:
Type: pressure switch set
Material: plastic and metal
Color: as shown
Switching pressure range 0.5-0.8mpa (5-8bar) (90-120psi)
Voltage
Exhaust pipe: about 6mm/0.24in
Contact method: normally closed
Connector size: about 12mm 1/4 inch
Outer pressure relief port: about 9.5mm/0.37in
Maximum current: 20A
Working pressure: about 5-8KG
Life: 80,000 times
Size: about 8 x 5 x 13.8 cm
Package includes:
1* Pressure switch
1* Pressure regulator
1* Safety
2* Pressure gauge
Notes:
Transition: 1cm=10mm=0.39inch
1. Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
2. Please allow 1-3cm measuring deviation due to manual measurement.
