Описание
Description:
100% brand new and high qualityDigital terrestrial video and radio programs recording.
Real time digital video recording .
Still image capture .
Pip (picture in picture).
One touch channel euto-scan at 6/7/8 MHz.
On-fly decode software technique.
Multi-language in stallation and application program.
Full DVB-T bandwidth reception .
Time-shifting.
Digital TV recording and playback as DVD quality.
Support for Microsoft DAB drivers.
Remote control.
Features:
Improved passive component tolerances
A 1 PPM temperature compensated oscillator (TCXO)
HF mode via direct sampling built in (can tune down to 500 kHz unlike basic RTL-SDR's which can only go to 24 MHz)
SMA F connector
Software activatable 4.5v bias tee circuit
Improved PCB design for lower noise and less spurs
A USB noise choke, more bypass capacitors, and built in ferrites for less PC noise
Improved ESD protection (additional ESD diode and extra ESD discharge paths)
An improved front end circuit designed for wideband use (other models still use a circuit designed for DVB-T only)
Several breakout pads on the PCB for advanced users
Specifications:
Interface :USB 2.0 Standard
Input : 75 Ohm IEC(Din) Connector
Output :A type USB male connect
Receiving frequency: FM radio: 87.5~108 MHZ
DAB radio: L-Band-1452960~1490624 KHZ
VHF—174928~ 239200 KHZ
TV system: Full DVB-T and DAB compliant
Bandwidth: 6/7/8 MHZ auto select for DVB-T
Power supply: USB bus
Consumed power: ≤1.5W
USB DVB-T Recorder size:8.5x2.5cm
Package Included:
1 x USB DVB-T TV Tuner Recorder
1 x Antenna
Notes:
Transition: 1cm=10mm=0.39inch
1. Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
2. Please allow 1-3cm measuring deviation due to manual measurement.
Характеристики
- Бренд
- Woopower
- Тип товара
- TV-тюнер
- Соединители
- USB
- Дистанционное управление
- Не включает
- Запись
- Нет
- Способность декодирования
- Стандарт
- Тип
- Высокое разрешение
